Mahle 4.000 Bore 3.622 Stroke 6.125 Rod -5.8cc LS2 L98 6.0 Forged Pistons and Rings 4032

SKU: 930227800
Mahle 4.005 Bore 3.622 Stroke 6.098 Rod -5.8cc LS2 L98 6.0 Forged Pistons and Rings 4032 Pistons
Mahle 4.000 Bore 3.622 Stroke 6.125 Rod -5.8cc LS2 L98 6.0 Forged Pistons and Rings 4032 - 4.000
Mahle 4.000 Bore 3.622 Stroke 6.125 Rod -5.8cc LS2 L98 6.0 Forged Pistons and Rings 4032 - 4.000
Mahle 4.000 Bore 3.622 Stroke 6.125 Rod -5.8cc LS2 L98 6.0 Forged Pistons and Rings 4032 - 4.000
Mahle 4.000 Bore 3.622 Stroke 6.125 Rod -5.8cc LS2 L98 6.0 Forged Pistons and Rings 4032 - 4.000
Mahle 4.000 Bore 3.622 Stroke 6.125 Rod -5.8cc LS2 L98 6.0 Forged Pistons and Rings 4032 - 4.000

Mahle 4.000 Bore 3.622 Stroke 6.125 Rod -5.8cc LS2 L98 6.0 Forged Pistons and Rings 4032

SKU: 930227800
Regular price $1,455.00
/
  • Secure payments
  • Low stock - 1 item left
  • Inventory on the way
Tax included.
Description

Mahle Motorsport Powerpak Forged Pistons 4032 High silicon material 930227800

Includes premium Mahle Performance low drag ring set (1.0,1.0,2.0mm file fit)

Suitable for LS1 LS2 LS6 LS3 L98 heads

First photo is generic. Use single piston photos for reference.

Listing is for a full set with rings

BORE

4.000"

STROKE

3.622"

ROD

6.125"

COMP HEIGHT

1.304"

PIN DIAMETER

0.927"

VOLUME

5.8CC (valve pocket)

WEIGHT

426G

MATERIAL

 4032 High silicon

COMPRESSION RATIO

62cc head=10.8

65cc head=10.4

71cc head=9.8

2618 Alloy has a low silicon content. 2618 alloy has a greater expansion rate but is higher strength and more resistant to harsh conditions. Because of the greater clearance required 2618 pistons can be noisy on start up but will go away when operating temperature is reached

     4032 Alloy has a higher silicon content. A great forged piston for power applications but less forgiving to detonation. Because of the lower expansion rate you generally run a tighter clearances which generally makes for a quieter engine. Great for street performance engines and owners who are looking for OE quiet operation and still able to handle power add-ons.

If you need any help finding the right piston for your build contact us Mon-Fri 8-4

  • Here at Malex Motorsports all of our items are in stock in our Sydney based store, ready to ship or pick up.
