10T Basic Hydraulic Hand Kit

SKU: QCP 10T-BK
10T Basic Hydraulic Hand Kit Tool
10T Basic Hydraulic Hand Kit Tool
10T Basic Hydraulic Hand Kit Tool

10T Basic Hydraulic Hand Kit

SKU: QCP 10T-BK
Regular price $640.00
/
  • Secure payments
  • Low stock - 1 item left
  • Inventory on the way
Tax included.
Description


10T Hydraulic Basic Kit features our 10T cylinder with hand pump

This kit is an entry level of HYDRAULICS only, into the Mechanics Mate Quick Changer Puller World. The hydraulic hand pump and combination of 10T cylinder can power all the attachments up to and including 12T easily (adaptor not included). With our optional step up adaptors you could attach it to 25T, 50T and 100T attachments, but it is unlikely you will have enough force to do the job. But you never know.

The 10T cylinder with 20mm stroke and 17mm through hole is a perfect start for all your removal and installation needs.

The 10T hydraulic cylinder in this kit is also fitted with a 5T quick change coupling and 17mm through hole. Features include:

  • The 5T coupling allows use on all 5T attachments.
  • With adaptor p/n QCP 5T-12T-17, can be used on all 12T attachments with little compromise.
  • Except for the QCP RHS120 cylinder, this is the shortest cylinder in the Mechanics Mate range.
  • Through hole is ideal for all pushing and pulling requirements.
  • Up to 16mm (5/8″) threaded rods can pass through the cylinder easily to be used for the installation and removal of bearings, bushings and anything else yo can think of. Mechanics Mate supplies a range of installation shafts for the installation of power steering pulleys and harmonic balancers.

Piston ends should always be used to protect the piston of the cylinder. Piston ends are available in many sizes and can vary depending on the application. The piston ends supplied in this kit will cover most applications.

This kit comes complete with:

  • 10T Hydraulic cylinder with 20mm(3/4″) stroke and 17mm through hole
  • 700Bar(10,000psi) air driven hydraulic pump with 1800mm (6′) hose and coupling
  • 25mm diameter piston end
  • 25mm diameter piston extension 18mm long
  • 25mm diameter piston extension 36mm long
  • 25mm diameter piston extension 54mm long
  • 53mm diameter piston end with 17mm hole
